Laying Machine
Leading Manufacturers, Exporters, Wholesaler, Retailer of Automatic Kerb Laying Machine and Concrete Kerb Laying Machine from Ahmedabad.
MOQ : 1 Piece
| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | AASPA,AASPA,Aaspa |
| Driven Type | Penaumatic, Mechanical |
| Color | Light White, Grey, Brown, Blue,Light Green,As Required |
| Condition | New |
| Automatic Grade | Semi Automatic, Manual |
| Power | 9-12kw |
| Certification | ISO 9001:2008 |
| Type | Kerb Laying Machine |
| Weight | 700-800kg |
| Warrenty | 5 Years |
| Model Name | AKM100 |
| Capacity | 1 Hours |
| Material | Mild Steel |
| Steering Type | Auto |
| Speed | 1 Km Hours |
| Wheel Type | 4 |
| Dimension | 1500x 1600x 490 cm |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union |
| Packaging Details | AASPA |
Preferred Buyer From
| Location | Anywhere in India |
- AKM-100 KERB PAVER that can extrude is excess of 550 lin. mts. of kerbing per day at a sensible capital cost and with a small crew of semi-skilled labour.
- AASPA AKM-100 Extrusion Type Kerb Paver Machine works on the extrusion principle, in which concrete is fed into the hopper and forced through a mould to form the required shape.
- AKM-100 is designed for laying up to 550 mm height and 700 mm width.
- The machine does not employ vibration, but achieves compaction by a ramming mechanism which forces the concrete into the specially designed mould attached to the primary unit.
- Automatic sensor for steering and height controls that follow reference line Activate Windows Go to Sete, to activate Nanclows.
- Quick-change mould design.
- The machine has no powered wheels - forward propulsion resultsfrom the opposite reaction to the ramming action.
- The flexibility mounted 16 hp petrol engine / 10 hp diesel engine drives the ruggedly designed ram operating mechanism and hydraulic pump.
- All top side covers are removable for ease of service.
- A small crew can successfully operate AKM-100.
- Production depends on crew size and outputs of up to 1000 lin. Mts. Per day have been achieved.
- AKM-100 is at multiple project sites with a variety of kerbing applications, supported by the team of experts from AASPA & performing to the full satisfaction of the customers.
MOQ : 1 Piece
| Business Type | Manufacturer, Exporter, Supplier |
| Model Number | AKM-100 |
| Driven Type | Mechanical |
| Color | Light White, Light Green, Grey, Blue, Black, As Required |
| Condition | New |
| Automatic Grade | Semi Automatic, Manual |
| Engine Power | 20-40BHp |
| Application | ISO 9001:2008 |
| Certification | ISO 9001:2008 |
| Type | Kerb Laying Machine |
| Weight | 700-800kg |
| Warranty | 1year |
| Model Name | AKM100 |
| Brand Name | Aaspa |
| Material | Mild Steel |
| Wheel Type | 4 |
| Length(without Mould) | 1945 mm |
| Length(with Mould) | 2710 mm |
| Height | 930mm |
| Width | 1155 mm |
| Weight with mould | 915 kgs |
| Moulds | M.S Moulds to Customer Specication |
| Fuel Consumption | Petrol Engine - 3.5 ltrs / hour & Diesel Engine -1.5 ltrs/Hour |
| Minimum Radius of kerb | 2.4 mtr |
| Drives | Main Drive -5/8”Pitch duplex chain/Hydraulics-VBelt |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, Other |
| Delivery Time | READY STOCK |
| Packaging Details | AASPA |
Preferred Buyer From
| Location | Anywhere in India |
- AKM-100 KERB PAVER that can extrude is excess of 550 lin. mts. of kerbing per day at a sensible capital cost and with a small crew of semi-skilled labour.
- AASPA AKM-100 Extrusion Type Kerb Paver Machine works on the extrusion principle, in which concrete is fed into the hopper and forced through a mould to form the required shape.
- AKM-100 is designed for laying up to 550 mm height and 700 mm width.
- The machine does not employ vibration, but achieves compaction by a ramming mechanism which forces the concrete into the specially designed mould attached to the primary unit.
- Automatic sensor for steering and height controls that follow reference line Activate Windows Go to Sete, to activate Nanclows
- Quick-change mould design.
- The machine has no powered wheels - forward propulsion resultsfrom the opposite reaction to the ramming action.
- The flexibility mounted 16 hp petrol engine / 10 hp diesel engine drives the ruggedly designed ram operating mechanism and hydraulic pump.
- All top side covers are removable for ease of service.
- A small crew can successfully operate AKM-100.
- AKM-100 is at multiple project sites with a variety of kerbing applications, supported by the team of experts from AASPA & performing to the full satisfaction of the customers.
