1.80 Lac - 2.80 Lac / Piece

180000 Piece (MOQ)

Business Type Manufacturer, Exporter, Supplier
Brand Name AASPA
Material Bitumen Sprayer
Driven Type Mechanical
Click to view more

Preferred Buyer From

Location Anywhere in India

Product Details

Color
Black, Grey, Light White
Condition
New
Application
Constructional, Industrial
Certification
ISO 9001:2008
Sprayer Type
Mechanical
Type
Bitumen Sprayer
Weight
800-1000kg
Warranty
5years
After-Sales Service Provided
1
Country of Origin
India
Model
Ae20
Capacity
Upto 20 Ton
Automatic Grade
Manual
Tank Material
Mild Steel
Fuel Type
Diesel
Trolley Wheel
4
Insulation
40mm thickwithglasswool
Temp.Gauze
0-3000C
Mainhole
450mm in diameter
Mounting
Self chassis mounted on wheels
PipeLength
3 Mitre
TypeofPipe
S.S.corrugated hosepipe
SprayingPressure
0-3Kg./cm2
BITUMEN PUMP
1.5
AIR COMPRESSOR
Standing make Aircompressor
BURNER
Fuel consumption 7-8 liters/hour
ENGINEFUEL TANK
Capacity 5liters
BURNER FUEL TANK
Capacity 20 liters
ENGINE
Standard make air cooled diesel engine powered by 6HP
Product Code
AASPA 2356
Payment Terms
L/C, D/A, D/P, T/T, Other
Packaging Details
AASPA

TANK

Tank is fabricated by a 5mm MS sheet and is coated by 40 mm glasswool. This is done to prevent heat loss. The outer covaring is galvanized. Galvanized tank is better as it has long life due to its anticorrosion properles Tank heeting is by a first stage. Heating pipeline of diameter e inches and scond stage is 6 inches. Manhole for maintenance or to all bitumen tank is if 500mm X 600mm. Manual Temperature guage is provided for temperature display upto 300 Degrees celcius.

BURNER

Single high pressure oil burner for adequate heating of viscose binder with oil consumtion of 7-8 Liters/hrs. Burner comatible with Diesel.

ENGINE

Single stage air cooled diasel enginer of 6.5 HP at 1500 RPM, Engine powers bitumen pump and air compressor. Fuel consumption is 0.7-1 Liters per hour.

BITUMEN PUMP AND AIR COMPRESSOR

Both bitumen pumps and air compressor are engine dilven. Bitumen pump is connected to the engine by a manual clutch. Just ongaging the clutch will activate the pump. Bitumen pump gear type 200 to 300 Liters per minute. 2 HP Single piston air compressor is provided.
